FEATURES
HW-20W small excavator is suitable for agricultural planting, landscaping, orchard trenching and fertilization, small earthwork engineering, municipal engineering, road repair, basement and indoor construction, concrete crushing, buried cables, laying of water pipes, garden cultivation and cleaning of rivers and ditches. Various operating environments such as silt engineering.
SPECIFICATIONS
Parameters | Unit | Datas |
Total Weight | kG | 2000 |
Mechanical/Pilot | Pilot | |
Emission Standards | EURO III | |
Engine Brand | Yanmar/ Kubota | |
Engine model | 370 | |
Engine power | kW | 10.3 |
Hydraulic pump brand | NACHI | |
Dispenser brand | Taifeng | |
Swing motor brand | Eaton | |
Walking motor brand | Eaton | |
Bucket capacity | m3 | 0.045 |
Overall Size | mm | 3160*1300*2370 |
Maximum digging depth K | mm | 1760 |
Maximum Digging Height F | mm | 3260 |
Maximum dump height M | mm | 2300 |
Maximum digging radius N | mm | 3470 |
Minimum turning radius | mm | 1440 |
Notes | a). mechanical b)Standard configuration: sunshade; extendable chassis; side swing. | |
※ The technical information may vary by the update policy, the changes will be without prior notice.
